Overall
     Weight

Operating

8125KG

Rated  dynamic  /Static
     load of front axle

9t/22.5t

Transport Dimension

Rated dynamic/Static
     load of front axle

7.5t/18.5t

mm L*W*H

5919×2217×3764

Transmission System

Wheel base

2200mm

Torque Converter

Min. Ground Clearance

300mm

Model

TLB1-4WD

Bucket Capacity

1.0m3

Type

Single-stage Three
     Elements

Breakout Force

47KN

Max. Efficiency

84.4%

Loading Lifting Capacity

2500KG

Inlet Pressure

0.4Mpa—0.55 Mpa

Bucket Dumping Height

2742mm

Outlet Pressure

1.2Mpa—1.5 Mpa

Bucket
     Distance

Dumping

1062mm

Cooling Method

Oil-cooling Pressure
     Circulation

Digging Depth

52mm

Gearbox

Backhoe Capacity

0.3 m3

Type

Fixed Shaft Power
     Transmission

Max. Digging Depth

4082mm

Oil Pressure of Clutch

1373Kpa—1569 Kpa

Swing Angle of Excavator
     Grab

190o

Gears

Four Gears Ahead, Four
     Gears Astern

Max. Pulling Force

60KN

Max.Speed

42Km/h

Engine

Tyre

Model

Cummins

Model

14-17.5/19.5L-24

Type

In Line Direct injection Four-Stroke and Injection   Combustion
     Chamber

Pressure of Front wheel

0.4Mpa

Cylinder-Inside
     Diameter*Stroke

4-110×120

Pressure of Back Wheel

0.35 Mpa

Rated Power

74KW

Brake System

Rated Speed

2200r/min

Service Brake

Wet type

Min. Fuel Consumption

≤216g/km.h

Internal type

Max.Torque

≥261.7N.M/1800r/min

Self-regulation

Displacement

3.9L

Self-balance

Steering System

Emergency Brake

Operation Power
     Implementing brake

Model Device

of

Steering

BZZ5-250

Manual Operation
     Power Terminating Brake

Steering Angle

±36 o

Hydraulic System

Pressure of the system

12Mpa

Digging Power of Dipper

31KN

Axle

Bucket Lifting Time

6.8S

Manufacturer

Carraro

Bucket Lowering Time

3.1S

Model

26.22-1920/28.43MM-1
     654

Bucket Discharge Time

2.0S
