Model

SY354C

Horsepower

35 HP

Dimensions

Length 2300mm Width 1000mm Height 900m

Track size

180-72-38

Chassis height:

200mm

Diesel Engine Brand

Changzhou engine  single cylinder engine

Engine speed

2200 rpm backfilling soil width 1m

Whole machine weight

Approximately 850 kgs

Fuel consumption

About 1 liter/0.16 acre

Walking speed

The fastest 15KM/h

Gearbox

Customized version of pure gear transmission

Gear

3 forward gears, one reverse gear, divided into high and low speeds, a total of 8 gears

track

The crawler track has strong gripping ability, suitable for small-scale operations such as orchards, greenhouses, woods, etc. It is composed of rubber + five-layer steel wire + iron skeleton, which is not easy to deviate and not easy to derail. Reasons (1. with guide rail 2. with added profile)

air filter

Clean the air filter after each work, and add proper amount of engine oil

Water tank

Water should be added at 3/1 of the water drift, otherwise it is easy to damage the machine parts and reduce the service life

transfer method

Gearbox mechanical transmission

Standard configuration implement

Rotary tillage

Rotary tiller width 1m, rotary tiller blade length 1950mm

weeding

Weeding width 1m scraping the ground and weeding

Backfill

Soil width 1m

Ditch

The trench width is 30cm, the depth is 30cm

Bulldozer

Shovel width 1m high 30cm, maximum ground clearance 25cm

efficient

Normally about 1-2 acres/hour

Optional configuration implement

Fertilize

All-in-one fertilizing, ditching and backfilling machine, the depth of 0-20CM is the deepest, the fertilizing bucket can hold about 30 kg of fertilizer

ridging

The upper ridge surface is up to 50CM, the lower ridge surface is up to 80CM, and the ridge surface is up to 30CM. You can also adjust the ridge surface and height and width according to your needs.

Double plough

Two plows and traction frame

Broken grass back to the field

The width of the machine is 0.8-1.2 meters, (stalk can be crushed)

Sprayer

The spray diameter is 15 meters, each nozzle can be adjusted independently
