model

7CX-3

7CX-4

7CX-9

 loading size(mm)

3200*1700*400

3800*1900*400

5500*2150*500

Outside dimension(mm)

4700*1800*1750

5100*2150*1850

7000*2250*2150

loading capacity

3 ton

4 ton

9 ton

dead weight

980kgs

1100kgs

2600kgs

tire/QTY

650-16   /   4

700-16   /   4

825-16  /  8

Brake forms

Air brake

Air brake

Air brake

match power

30-60hp

30-60hp

80-100hp

model

SY7CX-5

SY7CX-6

SY7CX-8

SY7CX-10

loading size(mm)

4000*2150*400

4200*2150*400

5300*2150*500

5600*2150*600

Outside dimension(mm)

5800*2250*1850

6300*2250*1950

7100*2250*2050

7300*2250*2250

loading capacity

5 ton

6 ton

8 ton

10 ton

dead weight

1200kgs

1400kgs

2300kgs

3200kgs

tire/QTY

750-16   /   4

825-16   /   4

750-16  /  8

825-16 /  8

Brake forms

Air brake

Air brake

Air brake

Air brake

match power

30-60hp

30-60hp

50-100hp

80-150hp
