Bucket Capacity

0.1

Swing Speed

1-10

Gradeablity

58

Max.Bucket Digging Force

23.5

Max.Arm Digging Force

14

Engine

Kubota  EPA

Engine Model

D1105-E4B

Power/revolution speed

14/2000

System Pressure

20.5

Machine size

Dimension Length*Width*Height

4195x1550x2480 mm

Cabin Height

2480 mm

Axle Base

1550 mm

Wheel(track) Distance

1250 mm

Minimum ground clearance

285 mm

Tail Swing Radius

860 mm

Working range

Max.Digging Height

4427 mm

Max.Dumping Height

3005 mm

Max.Digging Depth

2830 mm

Max.Vertical Digging Depth

2500 mm

Max.Digging Radius

4835 mm

Min.Swing Radius

2160 mm

Max.Dozer Blade Lifting Distance

308 mm

Max.Dozer Blade Cutting Distance

360 mm
