Features & Details
1. The engine needs to add oil: add it to the second grid of the oil dipstick
2. Fuel tank capacity: 20L
3. Refueling type: add about 16L of No. 8 hydraulic transmission oil to the gearbox position
4. Precautions for product maintenance: After the machine has been working for 20 hours, the oil of the entire vehicle must be changed. Gear oil must be added before the rotary tiller is used. This model does not need to add hydraulic oil.
5.50 horsepower bare machine: with suspension system
Specifications
Model | Crawler rotary cultivator SY504(S) |
Horsepower | 50 HP/36.8Kw |
Dimensions | 2500*1400*1500mm |
Track size | 350-90-54 |
Diesel Engine Brand | Laidong Engine |
Engine speed | 2400 rpm |
Whole machine weight | About 1500 kg |
Fuel consumption | 1-3 L /h |
Efficiency: | Normally about 3-5 acres/hour |
Braking mode | Mechanical friction brake |
Gear | (4+1)*2 |
PTO | 540/720r/min |
Link method: | Three point suspension |
Add farm tools: can be used with all wheeled tractor farm tools |
