Rated capacity

5000

kg

Load center

500

mm

Power type

Diesel

Transmission

Automatic

Dimensions

Lifting height

3000

mm

Free lifting height

150

mm

Turning radius

3000

mm

Overall length

4350

mm

Overall width

1400

mm

Overall height (mast lowered)

2330

mm

Overall height (mast lowered)

4265

mm

Overall height(overhead guard)

2330

mm

Fork length

1220

mm

Fork width

150

mm

Fork thickness

55

mm

Performance

Max. driving speed(with/without load)

20/24

km/h

Max. lifting speed(with load)

375

mm/s

Max. traction(with/without load)

31/18

kn

Gradeability (with/without load)

15/20

%

Tilting angles (forward/backward)

6/12

°

Service weight

6800

kg

Engine

Engine model

China QUANCHAI  4c6 ENGINE

Power

62.5

kw

83.8

hp

Rated speed

2200

rpm

Displacement

4.95

L

No. of cylinder

4

Wheel

Front overhang

585

mm

Wheel base

2150

mm

Front tread

1180

mm

Rear tread

1190

mm

Front tire

300-15

Rear tire

7.00-12
