Rated capacity

3500

kg

Load center

500

mm

Power type

Diesel

Transmission

Automatic

Dimensions

Lifting height

3000

mm

Free lifting height

80

mm

Turning radius

2500

mm

Overall Size(L*W*H)

3800*1230*2110

mm

Overall width

1230

mm

Overall height (mast lowered)

2110

mm

Overall height(mast raised)

4270

mm

Overall height (overhead guard)

2110

mm

Fork length

1220

mm

Fork width

125

mm

Fork thickness

45

mm

Performance

Max. driving speed(with/without load)

17/19

km/h

Max. lifting speed(with load)

375

mm/s

Max. traction (with/without load)

11/16

kn

Gradeability(with/without load)

15/20

%

(forward/backward)

6/12

°

Service weight

4580

kg

Engine

Engine model

C490BPG-223 engine

Power

40kw/53.6HP

Kw/ hp

Rated speed

2650

rpm

Displacement

2.67

L

No. of cylinder

4

Wheel

Front overhang

465

mm

Wheel base

1700

mm

Front tread

1000

mm

Rear tread

970

mm

Front tire

28x9-15

Rear tire

6.50+A30:E43-10
