Rated capacity

kg

3500

Load center

mm

500

Power type

LPG/Gasoline

Transmission

Automatic

Lifting height

mm

3000

Free lifting height

mm

80

Turning radius

mm

2500

Overall length

mm

3800

Overall width

mm

1230

Overall height

(mast lowered)

mm

2110

Overall height

(mast raised)

mm

4270

Overall height

(overhead guard)

mm

2110

Fork length

mm

1220

Fork width

mm

125

Fork thickness

mm

45

Max. driving speed

(with/without load)

km/h

18/20

Max. lifting speed

(with load)

mm/s

375

Max. traction

(with/without load)

kn

16/11

Gradeability

(with/without load)

%

15/20

Tilting angles

(forward/backward)

°

6/12

Service weight

kg

4580

Engine model

China gasoline engine

Power

kw

41

hp

55

Rated speed

rpm

2800

Displacement

L

2.237

No. of cylinder

4

Front overhang

mm

465

Wheel base

mm

1700

Front tread

mm

1000

Rear tread

mm

970

Front tire

28x9-15

Rear tire

6.50-10
