Matching power

16-35 hp

25-75 hp

45-85hp

50-100 hp

70—125hp

80-150hp

Dig deep

1850 mm

2150 mm

2640 mm

2900 mm

3000 mm

3500mm

Excavation depth flat bottom

1600 mm

2000 mm

2500 mm

2760 mm

2800 mm

3350mm

Excavation height

2500 mm

3400 mm

3510 mm

3900 mm

4000 mm

4300mm

Handling height

1400 mm

1760 mm

2000 mm

2362 mm

2637 mm

3000mm

Unloading height

1733 mm

1878 mm

1952  mm

2413 mm

2540 mm

2770mm

Reaching the excavation radius of the centerline

2800 mm

3360 mm

3930 mm

4377 mm

4586 mm

4800mm

Digging force

1300 kg

1200 kg

1600 kg

1900 kg

2600 kg

2700kg

Excavating force of shovel digging rod

790 kg

950 kg

1000 kg

1270 kg

1720 kg

1900 kg

Bucket rotation angle

160°

160°

160°

150°

150°

172°

Swing arc

140°

140°

140°

160°

160°

180°

Operating pressure

16 Mpa

16 Mpa

16 Mpa

16 Mpa

16 Mpa

16 Mpa

Excavation bucket width

300 mm

370 mm

420 mm

470 mm

520 mm

570 mm

Bucket capacity

0.03 m3

0.036 m3

0.048 m3

0.054 m3

0.06 m3

0.07 m3

Standard configuration: seats, fuel tank, fuel pump
