Features & Details
| Performance | Rated loading (kg) | 2800 |
| Rated loading（Max extension） (kg) | 1000 | |
| Max loading (kg) | 3100 | |
| Overall weight (kg) | 6300 | |
| Rated bucket capacity (CBM) | 1.2 | |
| Maximum tractive force (kN） | 30 | |
| Maximum breakout force (kN） | 10KN | |
| Maximum grade ability（°） | 25 | |
| Bucket maximum lift height（mm） | 6800 | |
| Fork maximum lift height（mm） | 6000 | |
| Maximum dump height（mm） | 5330 | |
| Maximum dump reach（mm） | 330 | |
| Overall dimension (L×W×H) （mm） | 5500*2200（Width）*2150（height） | |
| Minimum turning radius（outside of wheels）（mm） | 5000 | |
| Maximum steering angle | 30° | |
| Oscillation angle | 8° | |
| Engine | Model | Sitchai4DX21 |
| Type | lnline water cooled, four stroke | |
| No. of cylinder-bore/stroke （mm） | 4-102*118mm | |
| Displacement （L） | 3.857L | |
| Rated power（kW） | 53kw | |
| Idel speed (r/min) | 800-850 | |
| Rated speed (r/min) | 2400 | |
| Maximum torque N.m @speed r/min | 300Nm 1500-1700r/min | |
| Min fuel-consume ratio | 228g/(kw.h) | |
| Transmission system | Transmission converter | Closed hydrostatic drive |
| Gearbox mode | Pneumatic high and low speed shift | |
| Gear shift | 4forward shift 4reverse shift | |
| Maximum speed | 30km/h | |
| Drive axles | Main reducing mode | Bevel gear grade l reduction |
| Wheel base (mm) | 2850 | |
| Wheel tread(mm) | 1860 | |
| Ground clearance(mm) | 400 | |
| Hydraulic system | System working pressure (Mpa) | 20 |
| Boom lifting time (s) | 7 | |
| Total time (s) | 16 | |
| Fuel tank capacity (L) | 70 | |
| Brake system | Service brake | Air brake, hub brake |
| Parking brake | Air brake brake | |
| Tyre | Type specification | 14-17.5 |
| Front tyre pressure （kPa） | 350 | |
| Rear tyre pressure （kPa） |
Specifications
