1.0 Engine

(1) Brand/Model:

YUNNEI YN38GBZ

(2) Type:

In-line arrangement, water-cooled, four cylinder, turbocharged diesel engine

(3) Rated Power:

76KW

EURO5 YUCHAI
     EPA4 KOHLER/CUMMINS

2.0 Overall Dimensions

(1) Overall length:

6500mm

(2) Overall width:

2000mm

(3) Overall height:

2860mm

(4) Max. Discharge height:

4400mm

(5) Min. Discharge height:

3400mm

3.0 Transmission System
     Gearbox + hydraulic converter + drive shaft + hub reduction axle

4.0 Bucket：

(1) Capacity:

1.2m³

(2) Width:

2100mm

(3) Type:

Heavy-duty bolt on teeth

2500kg including bucket or attachment

5.0 Operating Specifications

Articulated hydraulic steering

1. Driving System:

Four wheel drive

Yes

Yes

(5) Steady rise

Yes

6.0 Brake System

(1) Service Brake:

Four wheel disc brake

(2) Parking Brake:

Disc brake

7.0 Tyre

(1) Model:

16/70-24 Herringbone tyre

(2) Size:

Width: 410mm
     Diameter: 1175mm

8.0 Wheel Base: 2550mm

9.0 Track: 1600mm

10.System Pressure:

20Mpa

11. Weight:

6000KG

12. Cabin

Yes

13.Reversing image

Yes

13.Optional:

Electronic control system;

Electric walking, telescopic, quick change, electric control handle

Cabin air conditioning
