Engine power

129KW

Number of cylinders

6

Cooling way

Water cooling

Engine type

Electronic Unit Injector Engine

Optional engine


6BT5.9-C150 CUMMINS
     EURO5 YTO/FPT
     EPA4 CUMMINS/KOHLER

Bucket

Bucket Capacity

2m³

Bucket width

2300mm

Bucket type

Heavy-duty teeth重型铲齿

Overall Dimensions

Overall Length

7800mm

Overall Height

3230mm

Overall Width

2300mm

Max. Discharge height:

5400mm

Min. Discharge height:

4000mm

Optional Max. discharge height:

7000mm
     9100mm

Tyre

Model

G2 pattern 20.5-25 Tyre

Size

Width: 520mm
     Diameter:1490mm

Transmission System

Hydraulic converter + gearbox + drive shaft + hub reduction axles

Brake System

Service Brake

Four Wheel Disk brake

Parking Brake

Hand operated

Braking Type

Air Brake

Steering System

Articulated hydraulic steering

Driving System

Four wheel drive

Hydraulic quick release

Yes

Hydraulic pilot joystick

Yes

Steady rise

Yes

Max. Load

4000kg including bucket or attachment

Wheelbase

2845mm

Track

1825mm

Speed

0-38km/H

Weight

10000kg(with bucket)

System Pressure

19Mpa

Hydraulic Output

184L/min

Fuel Tank Capacity

175L

Hydraulic Tank Capacity

175L
