SYNBON 120HP Wheel Tractor SY1204
Description
SYNBON 120HP farm tractor
4*4 ， 120hp，16F+8R Shifts,farm tractor
Description：
4WD
Power：120hp/96.5
Type: 13.6-24 16.9-34
Weight: 4100kg
Overall size : 4350*2130*2870 mm
Features & Details
Application:
Widely used in farmland, orchards, pastures, farms, greenhouses and other places
Tools can be selected:
Front loader, backhoe, rotary tiller, plow, harrow, lawn mower, trailer, sprayer and other agricultural tools
Specifications
SY1204 tractor:120hp, 4wd,four/six cylinder diesel engine,aumahr hood,power steering,16f+8r shifts,double stage cluth,front tyre:13.6-24 rear tyre:16.9-34 ,bouble speed pto: 540/1000rpm( 760/850 rpm ).big fuel tank, with fan cabin,with front and rear ballast.
Model | SY1204 |
Horsepower(hp) | 120 |
Type | 4×4 Wheeled tractor |
Overall dimension（mm） | |
length | 4350 |
width | 2130 |
Height | 2870 |
Tread（mm） | |
Front Wheel | 1625 |
Rear Wheel | 1608-1996 |
wheel base（mm） | 2530 |
Ground Clearance（mm） | 420 |
Structure weight（kgs） | 4100 |
Front Wheel ballast（kg） | 440 |
Rear Wheel ballast(kg) | 172 |
Engine | |
Type | vertical, water cooled, four/six cylinder,four stork |
Rated rev. (r/min) | 2300 |
Rated power (KW) | 88.2 |
clutch | Dry-friction,double stage |
Transmission system | |
gearbox | 16F+8R |
central transmission | Gear sector |
Tractor brake | Hydraulic brake,discs |
Tyre | |
front wheel | 12.4-24/13.6-24 |
Rear wheel | 16.9-34 |
PTO shaft rev. | 760/850 RPM(540r/min and 1000r/min) |
