SYNBON 180HP TRACTOR SY1804
Description
SYNBON 180HP farm tractor
4*4 ， 180hp，16F+8R Shifts,farm tractor
Description：
4WD
Power：180hp/132.3kw
Type: 14.9-26,/18.4-38
Weight: 5250kg
Overall size : 5120*2380*3100 mm
Features & Details
180HP 4WD,Six-cylinder weichai engine,16+8 gearbox, Dula-stage clutch, hydraulic steering, front tire 14.9-26, rear tire 18.4-38, PTO speed 760 and 850r/min, suspension attachment, front and rear ballast, luxry cabin,3 sets of hydraulic valves
Specifications
Model | SY1804 | |||
Type | 4WD | |||
Size (mm) | Length(to front ballast) | 5120 | ||
Width | 2380 | |||
Height(to top point) | 3100 | |||
Wheel Tread | Front | 1760/1860/1960/2060 Step adjustable | ||
Rear Wheel | 1700-1940 stepless adjustable | |||
Axle Base | 2630 | |||
Ground Clearance | 470 | |||
Structure weight (kg) | 5250 | |||
Engine | Model | Six-cylinder Weichai brand engine | ||
Type | 6-Cylinder,Water Cooled | |||
Rated Power(kw) | 132.5 | |||
Rated speed(r/min) | 2200 | |||
Fuel | Diesel | |||
Tire | Front Wheel | 14.9-26 | ||
Rear Wheel | 18.4-38 | |||
Clutch | 14'' LUKE clutch,Double-stage clutch | |||
Steering | Hydraulic steering | |||
Transmission Type | 16F+8R | |||
Suspension Type | 3-point links | |||
PTO | Type and speed | dual speed: 760rpm/850rpm | ||
Spline Size | I38 Rectangle Spline with 8 teeth | |||
