SYNBON 220HP TRACTOR SY2204
Description
SYNBON 220HP farm tractor
4*4 ， 220hp，16F+16R Shifts,farm tractor
Description：
4WD
Power：220hp/161.7kw
Type: 18.4-26 /20.8-38
Weight: 7815kg
Overall size : 5500*2780*3200 mm
Features & Details
SY2204 TRACTOR:220HP,4WD,SIX CYLINDER DIESEL ENGINE,AUMAHR HOOD,POWER STEERING,16F+16R 16F+16R SYNCHRONIZER SHIFTS,CARRARO FRONT AXLE,IMPORT HYDRAULIC ASSEMBLY,LUK CLUTCH,FRONT TYRE:18.4-26 REAR TYRE:20.8-38,,BOUBLE SPEED PTO: 540/1000RPM.BIG FUEL TANK,WITH A/C CABIN,WITH FRONT AND REAR BALLAST,WITH THREE-WAY HYDRAULIC OUTPUT,ADJUSTABLE STEERING WHEEL,CAT.III REAR SUSPENSION.
Specifications
Model | SY2204 | |
Horsepower(hp) | 220 | |
Type | 4×4 Wheeled tractor | |
Overall dimension（mm） | Length | 5500 |
Width | 2780/(Double rear Tyre 3880) | |
Height | 3200 | |
tread（mm） | Front Wheel | 2030 |
Rear Wheel | 1700-2500 | |
wheel base（mm） | 2830 | |
Ground Clearance（mm） | 340 | |
Structure mass（kg） | 7815 | |
Front Wheel ballast（kgs） | 1200 | |
Rear Wheel ballast(kgs) | 200 | |
ENGINE | Type | vertical, water cooled, six cylinder,four stork,turbo-charge,inner-cooling |
Rated rev. (r/min) | 2200 | |
Rated power (KW) | 162 | |
Steering | Power steering | |
Clutch | Dry-friction,double stage | |
Transmission system | Gearbox | 16F+16R Synchronizer Shifts |
central transmission | Gear sector | |
Tractor brake | Hydraulic brake,discs | |
Tyre | front wheel | 18.4-26 |
Rear wheel | 20.8-38 | |
PTO shaft rev. | 540r/min and 1000r/min | |
Fuel tank capacity | 390L | |
