SYNBON Orchard Tractor SY504G
Description
SYNBON 50HP farm tractor
4*4 ， 50hp，8F+2R Shifts,farm tractor
Description：
4WD
Power：50hp/36.8 kw
Type: 6.00-12/9.5-16
Weight: 1250 kg
Overall size : 2850*1240*1100 mm
Features & Details
50HP 4WD four cylinder engine,8F+2R shifts,power steering ,
Single stage clutch,double speed .PTO:540/720 Rpm.
New hood ,Tyre 6.00-12/9.5-16 .Front and rear ballast.
Specifications
Model | SY504(G) |
Type | 2WD/4WD |
Dimensions of Tractor (mm) | |
Length | 2850 |
Width | 1240 |
Height | 1100 to steering height |
Tread (mm) | |
Front Wheel | 950 |
Rear Wheel | 960 |
Wheel Base | 1500 |
Ground Clearance | 200 |
Structure mass (kg) | 1250 |
Standard counterweight (front) | 12 |
Standard counterweight (rear) | 44 |
Turning radius (mm) | 2800 |
Seat height (mm) | 1100 |
Engine | |
Type | Vertical, water cooled , 4-stroke,4-cylinder |
Rated Power（kw） | 36.8 |
Rated Rev.（r/min） | 2400 |
Fuel | Diesel Oil |
Clutch | Dry-friction，single stage |
Transmission system | |
Gearbox | (4+1)×2 ，8F+2R SHIFTS |
central trnsmission | Gear sector |
Tractor brake | Dry brake discs |
Tire | |
Front Wheel | 6.0-12 |
Rear Wheel | 9.5-16 |
PTO shaft rev | 540/720 r/min |
Hydraulic oil pump flow | 28L/min |
Hydraulic oil pump pressure: | 28 MPa |
