25HP Orchard Tractor SY254（G）
Description
SERIES TRACTOR:25HP,4WD,THREE CYLINDER ENGINE ,8F+2R SHIFTS,POWER STEERING,SINGLE STAGE CLUTCH,DOUBLE SPEED PTO:540/720 RPM, NEW HOOD,TYRE:6.00-16/9.5-24,FRONT AND REAR BALLAST
Features & Details
Specifications
SERIES TRACTOR:25HP,4WD,THREE CYLINDER ENGINE ,8F+2R SHIFTS,POWER STEERING,SINGLE STAGE CLUTCH,DOUBLE SPEED PTO:540/720 RPM, NEW HOOD,TYRE:6.00-16/9.5-24,FRONT AND REAR BALLAST | |
Model | SY254(G) |
Horsepower(hp) | 25 HP |
Type | 4WD |
Overall dimension（mm） | Overall dimension（mm） |
length | 2900 |
width | 1300 |
Height | 1200 |
tread（mm） | |
Front Wheel | 1100 |
Rear Wheel | 1200 |
wheel base（mm） | 1512 |
Ground Clearance（mm） | 216 |
Structure mass（kg） | 1360 |
Front Wheel ballast（kg） | 48 |
Rear Wheel ballast(kg) | 50 |
Engine | |
Type | vertical, water cooled, Three /four cylinder,four stork |
Rated rev. (r/min) | 2400 |
Rated power (KW) | 18.4 |
clutch | Dry-friction,single- stage |
Transmission system | |
Gearbox | （4+1)X2 ,8F+2R SHIFTS |
central transmission | Gear sector |
Tractor brake | Dry brake,discs |
Tyre | |
front wheel | 6.00-16/6.50-16 |
Rear wheel | 9.5-24/11.2-24 |
PTO shaft rev. | 540/720r/min |
