Rated capacity

2500

kg

Load center

500

mm

Power type

Diesel

Transmission

Automatic

Dimensions

Lifting height

3000

mm

Free lifting height

80

mm

Turning radius

2450

mm

Overall length

3605

mm

Overall width

1160

mm

Overall height (mast lowered)

2095

mm

Overall height (overhead guard)

2110

mm

Fork length

1070

mm

Fork width

122

mm

Fork thickness

40

mm

Performance

Max. driving speed(with/without load)

17/ 19

km/h

Max. lifting speed(with load)

400

mm/s

Max. traction(with/without load)

15/ 10

kn

Gradeability(with/without load)

15/20

%

Tilting angles(forward/backward)

6/ 12

°

Service weight

3600

kg

Engine

Engine model

China Xinchai

C490BPG-223

engine

Power

40kw/53.6hp

kw/hp

Rated speed

2650

rpm

Displacement

2.67

L

No. of cylinder

4

Wheel

Front overhang

451

mm

Wheel base

1640

mm

Front tread

970

mm

Rear tread

970

mm

Front tire

7.00-12

Rear tire

6.00-9
