SYNBON 40hp Orchard Tractor
Description
Model: SY404G
Horsepower: 40HP/29.4kw
Length*Width*Height: 2400*1200*1100mm
Weight: 1210kg
Front / Rear Wheel Tire: 6.00-12/9.5-16
Condition:
Used in small places such as orchards, greenhouses, factories, gardens, etc.
Low body, high safety, small turning radius, suitable for small places
Features & Details
Packaging & Shipping
8unit in 1*20GP container , 16units in 1*40HQ container , Triangle wood and 10mm wire fixed.
40HP,4WD,FOUR CYLINDER ENGINE ,8F+2R SHIFTS,POWER STEERING,
SINGLE STAGE CLUTCH,DOUBLE SPEED PTO:720RPM, NEW HOOD,TYRE:6.00-12/9.5-16,FRONT AND REAR BALLAST
Specifications
Model | SY404 |
Horsepower(hp) | 40 |
Type | 4×4 Wheeled tractor |
Overall dimension（mm） | |
length | 2400 |
width | 1200 |
Height | 1100 |
Tread（mm） | |
Front Wheel | 950 |
Rear Wheel | 960 |
wheel base（mm） | 1200 |
Ground Clearance（mm） | 210 |
Structure weight（kg） | 1210 |
Front Wheel ballast（kg） | 12 |
Rear Wheel ballast(kg) | 50 |
Engine | |
Type | vertical, water cooled, four cylinder,four stork |
Rated rev. (r/min) | 2200 |
Rated power (KW) | 29.4 |
clutch | Dry-friction,single- stage |
Transmission system | |
gearbox | (4+1)X2 ,8F+2R shifts |
central transmission | Gear sector |
Tractor brake | Dry brake,discs |
Tyre | |
front wheel | 6.00-12 |
Rear wheel | 9.5-16 |
PTO shaft rev. | 720 r/min |
